Specifications:
| Place of Origin: | Shandong, China |
| Brand Name: | March House |
| Model Number: | MH-CH2501 |
| Certification: | SGS, BV, CE |
| LENGTH | WIDTH | HEIGHT | TARE WEIGHT | ||||
| EXTERIOR | INTERIOR | EXTERIOR | INTERIOR | EXTERIOR | INTERIOR | ||
| Metric(mm) | 6,055 | 5,845 | 2,438 | 2,230 | 2,896 | 2,510 | 1,700KG |
| F in | 19.8’ | 19.17’ | 8’ | 7.31’ | 9.5’ | 8.23’ | 3,748LB |
Standard Features:
● Structural design life for 20 years at the least
● Floor live load: 2.0 kn/㎡; Roof live load: 1.0 kn/㎡; Wind load: 0.6 kn/㎡
● Seismic fortification intensity is 8 degrees (GB50011) (which is reated to Seismic Design Catgegory D.)
● Can be connected to create larger complexes in multi-story configurations up to 3 modules high
● Electrostatic spaying painting
● 2.5mm-thick Galvanized cold-formed steel frame
● 3.0mm-thick Galvanized steel post
● 0.5mm-thick Zinc metal sheet roof
● 75mm-thick mineral wool insulation
● Type II B Noncombustible
● 1 set of standard forklift pockets
● 2 sets of single-glass sliding windows, 930mm*1200mm
● 1 set of external door, 970mm*1970mm opening
● Can be transported on flatbed trucks for over the road deliveries
● Electrical system (220V/240V, single phase; 3-hole socket*1pcs; 5-hole socket*3pcs; single switch *1pcs; distribution box*1pcs; industrial socket*1set; electrical wires; 2 lamps-36W
Optional Features:
● Heating and Cooling Unit: 12,000/10,000BTU (cool/heat)
● Stairs and platforms
● Furniture (desk, tables and chairs)
● Security Window Screens
● Steel Door, Window(Tilt&turn), Panic Bar & Door Closer
● Bathroom (toilet, wash basin, shower cube)
Applications:
With its low cost and easy for assembling, this kind of detachable prefabricated container house are more popular in the mining field for worker camp.
Advantages：
Energy saving and environment friendly;
Easy for loading and unloading;
Installation in 4 hours by 4 workers with one lifting truck;
Combine two or more units to get any space or size you want to get
